Sending emails via a map in iMIS

This iPart uses the ArcGIS Javascript API to initiate an email to a selected region of contacts on an interactive map.

GEOLOCATION

Purpose

This tool was created to easily contact groups of growers by email for targeted communications. This provides custom access to growers, on demand.

Stage 1: As a web page

The first iteration is a standalone HTML page that plots given coordinates, and a user can draw an area onto the map interface. An email can then be prompted by pressing the “email” button, which includes all of the email addresses in the selected region.

The ArcGIS API uses lots of dojo, which is a JS framework, and something I was not at all familiar with. In this application we require the following libraries.

// Javascript
dojo.require("esri.map");
dojo.require("esri.toolbars.draw");
dojo.require("esri.tasks.query");
dojo.require("esri.graphic");
dojo.require("esri.geometry.Point");
dojo.require("esri.InfoTemplate");
dojo.require("esri.symbols.SimpleMarkerSymbol");
dojo.require("esri.renderers.SimpleRenderer");

dojo.require is a way for us to load in relevant scripts.

Formatting

Notice how the selected points are highlighted? This is to show the user which points have been selected by their drawn area. In order to

// Javascript
//initialize points - HortNZ colours to be consistent with brand standards
defaultSymbol = new esri.symbol.SimpleMarkerSymbol().setColor(new dojo.Color([140,198,63])).setSize(10);
highlightSymbol = new esri.symbol.SimpleMarkerSymbol().setColor(new dojo.Color([230,255,160])).setSize(10);

Email

The email message is easily set up from the results of each plot point in the selected region. To do this you need to configure the

Stage 2: As an iPart

The next step is to use real data from iMIS, live and in real-time. For this task we require our database to become a geoDB. I’m also going to build this in an .ascx controller script, rather than a complete iPart. The script will have both C# and Javascript script tags, so that we can work with the ArcGIS API in Javascript.

Geocoding

To create a geoDB we geocode all of the addresses in iMIS from the address table, to create a geolocation table, which we are going to import back into iMIS. For this task we use the google maps API. Since we only need to do this once, I use python for the script along with the geocoder library. Unfortunately the API only allows 2500 free requests per day, since there are more than that in our database, we run this on batches over multiple days. The imports look like this:

# Python
import geocoder as g
import pandas as pd

# geocode addresses:

Connecting C# and Javascript

Unfortunately there is a flaw in using both C# and JS - which is array sharing. Since the data is pulled from a secure connection, we can only use a protected class. But we need to pass the array of growers from the server side through to the javascript on the client side, which isn’t that straightforward to do.

The C# code uses the Asi.Data.Dataserver object to connect to the database.

// C#
protected override void OnLoad(EventArgs e) {

    Asi.Data.DataServer dserver = new Asi.Data.DataServer(Asi.iBO.iboAdmin.ConnectionString);
    string query = "select company,email from NAME where status = 'A' and email != ''";
    System.Data.SqlClient.SqlDataReader reader = dserver.ExecuteReader(System.Data.CommandType.Text, query);
    if (reader.HasRows)
    {
        // temporary data string
        string dat = "";
        while(reader.Read())
        {
           dat = dat + "," +  reader["email"] as string;
     	}
        reader.Close();
        data.Text = dat;
    }
}

While there is almost certainly a better way to do this, what I have done is save the array in a hidden <p> tag in C#, then read it to an array with javascript.

To do this, we first need the query results. This is a straightforward SQL query which should look something like (query not exactly the same):

-- SQL
SELECT Latitude,Longitude,Company,Email FROM Name
INNER JOIN Geolocation
ON Name.Address_Number = Geolocation.Address_Number
WHERE Email != ''
AND Status = 'A';

Integrating with iMIS dashboards / pages

Since our .ascx file is implanted into the body field, and our We make another script tag to “inject” html, css and javascript into the head of the webpage.

// Javascript
function loadCSS(filename) {
        var file = document.createElement("link");
        file.setAttribute("rel", "stylesheet");
        file.setAttribute("type", "text/css");
        file.setAttribute("href", filename);
        document.head.appendChild(file);
}
//load the new CSS
loadCSS("https://js.arcgis.com/3.20/dijit/themes/claro/claro.css");
loadCSS("https://js.arcgis.com/3.20/esri/css/esri.css");

// add the body class to be claro for mapping
document.getElementsByTagName("body")[0].class = "claro";
document.getElementsByTagName("body")[0].onload = "updateVariables()";

Once the .ascx file has been created, it is easy to import into an iMIS page in RiSE.

ArcGIS-iMIS

Using geospatial data for advanced communications
